Forklift Brakes - A brake drum is in which the friction is supplied by the brake pads or brake shoes. The pads or shoes press up against the rotating brake drum. There are a few other brake drums types with certain specific differences. A "break drum" would normally refer to when either shoes or pads press onto the interior surface of the drum. A "clasp brake" is the term used in order to describe whenever shoes press against the outside of the drum. One more type of brake, referred to as a "band brake" utilizes a flexible band or belt to wrap around the outside of the drum. Where the drum is pinched in between two shoes, it can be called a "pinch brake drum." Similar to a conventional disc brake, these kinds of brakes are quite rare.
Prior to 1955, early brake drums needed consistent adjustment periodically so as to compensate for drum and shoe wear. Long brake pedal or "Low pedal" travel is the hazardous outcome if modifications are not done satisfactorily. The vehicle could become dangerous and the brakes could become ineffective if low pedal is combined with brake fade.
There are some different Self-Adjusting systems meant for braking accessible these days. They can be classed into two individual categories, the RAD and RAI. RAI systems are built in systems which help the tool recover from overheating. The most well known RAI manufacturers are Lucas, Bosch, AP and Bendix. The most well-known RAD systems include AP, Bendix, Ford recovery systems and Volkswagen, VAG.
Self-adjusting brakes normally make use of a tool that engages only whenever the motor vehicle is being stopped from reverse motion. This stopping technique is satisfactory for use where all wheels utilize brake drums. Nearly all vehicles nowadays make use of disc brakes on the front wheels. By functioning only in reverse it is less probable that the brakes would be applied while hot and the brake drums are expanded. If adapted while hot, "dragging brakes" could happen, which increases fuel intake and accelerates wear. A ratchet tool that becomes engaged as the hand brake is set is another way the self repositioning brakes can function. This means is just suitable in applications where rear brake drums are used. When the parking or emergency brake actuator lever goes beyond a particular amount of travel, the ratchet developments an adjuster screw and the brake shoes move toward the drum.
There is a manual adjustment knob placed at the base of the drum. It is generally adjusted via a hole on the other side of the wheel and this involves going underneath the lift truck using a flathead screwdriver. It is of utmost importance to be able to move the click wheel properly and adjust every wheel equally. If unequal adjustment occurs, the vehicle can pull to one side during heavy braking. The most effective method in order to make sure this tiresome task is accomplished safely is to either lift each and every wheel off the ground and spin it by hand while measuring how much force it takes and feeling if the shoes are dragging, or give every\each and every one the exact amount of manual clicks and then do a road test.
