Mast Chains - Utilized in various functions, leaf chains are regulated by ANSI. They could be utilized for forklift masts, as balancers between heads and counterweight in several machine gadgets, and for low-speed pulling and tension linkage. Leaf chains are sometimes even referred to as Balance Chains.
Construction and Features
Leaf chains are steel chains using a simple link plate and pin construction. The chain number refers to the pitch and the lacing of the links. The chains have specific features like high tensile strength for every section area, which allows the design of smaller mechanisms. There are B- and A+ kind chains in this particular series and both the BL6 and AL6 Series contain the same pitch as RS60. Finally, these chains cannot be powered utilizing sprockets.
Handling and Selection
Comparably, in roller chains, all of the link plates maintain higher fatigue resistance due to the compressive stress of press fits, whereas in leaf chains, just two outer plates are press fit. The tensile strength of leaf chains is high and the utmost allowable tension is low. When handling leaf chains it is important to confer with the manufacturer's instruction booklet in order to ensure the safety factor is outlined and utilize safety guards at all times. It is a good idea to apply extreme caution and use extra safety guards in functions wherein the consequences of chain failure are serious.
Utilizing much more plates in the lacing causes the higher tensile strength. As this does not improve the utmost acceptable tension directly, the number of plates used can be limited. The chains require frequent lubrication for the reason that the pins link directly on the plates, generating a very high bearing pressure. Making use of a SAE 30 or 40 machine oil is normally advised for most applications. If the chain is cycled over one thousand times day by day or if the chain speed is more than 30m for every minute, it would wear really fast, even with continual lubrication. Hence, in either of these conditions using RS Roller Chains will be a lot more suitable.
AL type chains are only to be used under particular situations such as where there are no shock loads or when wear is not really a huge concern. Be positive that the number of cycles does not exceed one hundred day after day. The BL-type will be better suited under other situations.
If a chain using a lower safety factor is chosen then the stress load in parts would become higher. If chains are utilized with corrosive elements, then they may become fatigued and break somewhat easily. Doing regular maintenance is really important if operating under these types of situations.
The outer link or inner link kind of end link on the chain would determine the shape of the clevis. Clevis connectors or Clevis pins are constructed by manufacturers, but the user usually provides the clevis. A wrongly constructed clevis could reduce the working life of the chain. The strands should be finished to length by the maker. Check the ANSI standard or phone the maker.
